Procesory Intel

--- Essentials ---
Product Collection : Intel® Core™ i5 processors (14th gen)
Code Name : Products formerly Raptor Lake
Vertical Segment : Desktop
Processor Number : i5-14400F
Lithography : Intel 7

--- CPU Specifications ---
Total Cores : 10
# of Performance-cores : 6
# of Efficient-cores : 4
Total Threads : 16
Max Turbo Frequency : 4.7 GHz
Performance-core Max Turbo Frequency : 4.7 GHz
Efficient-core Max Turbo Frequency : 3.5 GHz
Performance-core Base Frequency : 2.5 GHz
Efficient-core Base Frequency : 1.8 GHz
Cache : 20 MB Intel® Smart Cache
Total L2 Cache : 9.5 MB
Processor Base Power : 65 W
Maximum Turbo Power : 148 W

--- Supplemental Information ---
Marketing Status : Launched
Launch Date : Q1'24
Embedded Options Available : No
Use Conditions : PC/Client/Tablet

--- Memory Specifications ---
Max Memory Size (dependent on memory type) : 192 GB
Memory Types : Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s
Max # of Memory Channels : 2
Max Memory Bandwidth : 76.8 GB/s

--- Expansion Options ---
Direct Media Interface (DMI) Revision : 4.0
Max # of DMI Lanes : 8
Scalability : 1S Only
PCI Express Revision : 5.0 and 4.0
PCI Express Configurations : Up to 1x16+4 | 2x8+4
Max # of PCI Express Lanes : 20

--- Package Specifications ---
Sockets Supported : FCLGA1700
Max CPU Configuration : 1
Thermal Solution Specification : PCG 2020C
TJUNCTION : 100°C
Package Size : 45.0 mm x 37.5 mm
Max Operating Temperature : 100 °C

--- Advanced Technologies ---
Intel® Volume Management Device (VMD) : Yes
Intel® Gaussian & Neural Accelerator : 3.0
Intel® Thread Director : Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Intel® Speed Shift Technology : Yes
Intel® Turbo Boost Technology : 2.0
Intel® Hyper-Threading Technology : Yes
Intel® 64 : Yes
Instruction Set : 64-bit
Instruction Set Extensions : Intel® SSE4.1 | Intel® SSE4.2 | Intel® AVX2
Idle States : Yes
Enhanced Intel SpeedStep® Technology : Yes
Thermal Monitoring Technologies : Yes

--- Security & Reliability ---
Intel® Standard Manageability (ISM) : Yes
Intel® Control-Flow Enforcement Technology : Yes
Intel® AES New Instructions : Yes
Secure Key : Yes
Intel® OS Guard : Yes
Execute Disable Bit : Yes
Intel® Boot Guard : Yes
Mode-based Execute Control (MBEC) : Yes
Intel® Virtualization Technology (VT-x) : Yes
Intel® Virtualization Technology for Directed I/O (VT-d) : Yes
Intel® VT-x with Extended Page Tables (EPT) : Yes

--- Essentials ---
Product Collection : Intel® Core™ Ultra Processors (Series 2)
Code Name : Products formerly Arrow Lake
Vertical Segment : Desktop
Processor Number : 285K
Overall Peak TOPS (Int8) : 36

--- CPU Specifications ---
Total Cores : 24
# of Performance-cores : 8
# of Efficient-cores : 16
Total Threads : 24
Max Turbo Frequency : 5.7 GHz
Intel® Thermal Velocity Boost Frequency : 5.7 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency : 5.6 GHz
Performance-core Max Turbo Frequency : 5.5 GHz
Efficient-core Max Turbo Frequency : 4.6 GHz
Performance-core Base Frequency : 3.7 GHz
Efficient-core Base Frequency : 3.2 GHz
Cache : 36 MB Intel® Smart Cache
Total L2 Cache : 40 MB
Processor Base Power : 125 W
Maximum Turbo Power : 250 W
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
AI Software Frameworks Supported by CPU : OpenVINO™ | WindowsML | DirectML | ONNX RT | WebNN
CPU Lithography : TSMC N3B

--- Supplemental Information ---
Marketing Status : Launched
Launch Date : Q4'24
Embedded Options Available : No
Use Conditions : PC/Client/Tablet | Workstation

--- Memory Specifications ---
Max Memory Size (dependent on memory type) : 256 GB
Memory Types : Up to DDR5 6400 MT/s
Maximum Memory Speed : 6400 MHz
Max # of Memory Channels : 2
ECC Memory Supported : Yes

--- GPU Specifications ---
GPU Name : Intel® Graphics
Graphics Base Frequency : 300 MHz
Graphics Max Dynamic Frequency : 2 GHz
GPU Peak TOPS (Int8) : 8
Graphics Output : DP2.1 UHBR20 | HDM2.1 FRL 12GHz | eDP1.4b
Xe-cores : 4
Max Resolution (HDMI) : 4K @ 60Hz (HDMI 2.1 TMDS) 8K @ 60Hz (HDMI2.1 FRL)
Max Resolution (DP) : 8K @ 60Hz
Max Resolution (eDP - Integrated Flat Panel) : 4K @ 60Hz
DirectX* Support : 12
OpenGL* Support : 4.5
OpenCL* Support : 3
Intel® Quick Sync Video : Yes
# of Displays Supported : 4
Device ID : 0x7D67
Intel® Deep Learning Boost (Intel® DL Boost) on GPU : Yes

--- NPU Specifications ---
NPU Name : Intel® AI Boost
NPU Peak TOPS (Int8) : 13
Sparsity Support : Yes
Windows Studio Effects Support : Yes
AI Software Frameworks Supported by NPU : OpenVINO™ | WindowsML | DirectML | ONNX RT | WebNN

--- Expansion Options ---
Direct Media Interface (DMI) Revision : 4
Max # of DMI Lanes : 8
Intel® Thunderbolt™ 4 : Yes
Scalability : 1S Only
PCI Express Revision : 5.0 and 4.0
PCI Express Configurations : Up to 1x16+2x4 | 2x8+2x4 | 1x8+4x4
Max # of PCI Express Lanes : 24

--- Package Specifications ---
Sockets Supported : FCLGA1851
Thermal Solution Specification : PCG 2020A
Max Operating Temperature : 105 °C

--- Advanced Technologies ---
Intel® Volume Management Device (VMD) : Yes
Intel® Gaussian & Neural Accelerator : 3.5
Intel® Thread Director : Yes
Intel® Speed Shift Technology : Yes
Intel® Thermal Velocity Boost : Yes
Intel® Turbo Boost Max Technology 3.0 : Yes
Intel® Turbo Boost Technology : 2.0
Intel® 64 : Yes
Instruction Set : 64-bit
Instruction Set Extensions : Intel® SSE4.1 | Intel® SSE4.2 | Intel® AVX2
Idle States : Yes
Enhanced Intel SpeedStep® Technology : Yes
Thermal Monitoring Technologies : Yes

--- Security & Reliability ---
Intel vPro® Eligibility : Intel vPro® Enterprise
Intel® Hardware Shield Eligibility : Yes
Intel® Threat Detection Technology (TDT) : Yes
Intel® Active Management Technology (AMT) : Yes
Intel® Standard Manageability (ISM) : Yes
Intel® Remote Platform Erase (RPE) : Yes
Intel® One-Click Recovery : Yes
Intel® Control-Flow Enforcement Technology : Yes
Intel® Total Memory Encryption - Multi Key : Yes
Intel® AES New Instructions : Yes
Secure Key : Yes
Intel® Trusted Execution Technology : Yes
Execute Disable Bit : Yes
Intel® OS Guard : Yes
Intel® Boot Guard : Yes
Mode-based Execute Control (MBEC) : Yes
Intel® Stable IT Platform Program (SIPP) : Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp) : Yes
Intel® Virtualization Technology (VT-x) : Yes
Intel® Virtualization Technology for Directed I/O (VT-d) : Yes
Intel® VT-x with Extended Page Tables (EPT) : Yes

--- Essentials ---
Product Collection : Intel® Core™ i5 processors (14th gen)
Code Name : Products formerly Raptor Lake
Vertical Segment : Desktop
Processor Number : i5-14400
Lithography : Intel 7

--- CPU Specifications ---
Total Cores : 10
# of Performance-cores : 6
# of Efficient-cores : 4
Total Threads : 16
Max Turbo Frequency : 4.7 GHz
Performance-core Max Turbo Frequency : 4.7 GHz
Efficient-core Max Turbo Frequency : 3.5 GHz
Performance-core Base Frequency : 2.5 GHz
Efficient-core Base Frequency : 1.8 GHz
Cache : 20 MB Intel® Smart Cache
Total L2 Cache : 9.5 MB
Processor Base Power : 65 W
Maximum Turbo Power : 148 W

--- Supplemental Information ---
Marketing Status : Launched
Launch Date : Q1'24
Embedded Options Available : Yes
Use Conditions : PC/Client/Tablet

--- Memory Specifications ---
Max Memory Size (dependent on memory type) : 192 GB
Memory Types : Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s
Max # of Memory Channels : 2
Max Memory Bandwidth : 76.8 GB/s

--- GPU Specifications ---
GPU Name : Intel® UHD Graphics 730
Graphics Max Dynamic Frequency : 1.55 GHz
Graphics Output : eDP 1.4b | DP 1.4a | HDMI 2.1
Execution Units : 24
Max Resolution (HDMI) : 4096 x 2160 @ 60Hz
Max Resolution (DP) : 7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel) : 5120 x 3200 @ 120Hz
DirectX* Support : 12
OpenGL* Support : 4.5
OpenCL* Support : 3.0
Multi-Format Codec Engines : 1
Intel® Quick Sync Video : Yes
Intel® Clear Video HD Technology : Yes
# of Displays Supported : 4
Device ID : 0x4682/0xA782

--- Expansion Options ---
Direct Media Interface (DMI) Revision : 4.0
Max # of DMI Lanes : 8
Scalability : 1S Only
PCI Express Revision : 5.0 and 4.0
PCI Express Configurations : Up to 1x16+4 | 2x8+4
Max # of PCI Express Lanes : 20

--- Package Specifications ---
Sockets Supported : FCLGA1700
Max CPU Configuration : 1
Thermal Solution Specification : PCG 2020C
TJUNCTION : 100°C
Package Size : 45.0 mm x 37.5 mm
Max Operating Temperature : 100 °C

--- Advanced Technologies ---
Intel® Volume Management Device (VMD) : Yes
Intel® Gaussian & Neural Accelerator : 3.0
Intel® Thread Director : Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Intel® Speed Shift Technology : Yes
Intel® Turbo Boost Technology : 2.0
Intel® Hyper-Threading Technology : Yes
Intel® 64 : Yes
Instruction Set : 64-bit
Instruction Set Extensions : Intel® SSE4.1 | Intel® SSE4.2 | Intel® AVX2
Idle States : Yes
Enhanced Intel SpeedStep® Technology : Yes
Thermal Monitoring Technologies : Yes

--- Security & Reliability ---
Intel® Standard Manageability (ISM) : Yes
Intel® Control-Flow Enforcement Technology : Yes
Intel® AES New Instructions : Yes
Secure Key : Yes
Intel® OS Guard : Yes
Execute Disable Bit : Yes
Intel® Boot Guard : Yes
Mode-based Execute Control (MBEC) : Yes
Intel® Virtualization Technology (VT-x) : Yes
Intel® Virtualization Technology for Directed I/O (VT-d) : Yes
Intel® VT-x with Extended Page Tables (EPT) : Yes

Gniazdo procesora (socket) : Socket 1851
Architektura : Arrow Lake
Taktowanie rdzenia : 3.3 GHz (5.5 GHz w trybie turbo)
Liczba rdzeni fizycznych : 20 rdzeni
Typy rdzeni : 8 rdzeni Performance, 12 rdzeni Efficient
Liczba wątków : 20 wątków
Odblokowany mnożnik : Tak
Pamięć podręczna : 36 MB
Zintegrowany układ graficzny : Tak
Model układu graficznego : Intel Graphics
Rodzaj obsługiwanej pamięci : DDR5-6400
Proces litograficzny : 3 nm
Pobór mocy (TDP) : 125 W
Maksymalna Moc Turbo (MTP) : 250 W
Zastosowane technologie : Intel Turbo Boost Max 3.0, Intel Deep Learning Boost
Wersja : Tray
Gwarancja : 36 miesięcy

--- Essentials ---
Product Collection : Intel® Core™ i7 Processors (14th gen)
Code Name : Products formerly Raptor Lake
Vertical Segment : Desktop
Processor Number : i7-14700K
Lithography : Intel 7

--- CPU Specifications ---
Total Cores : 20
# of Performance-cores : 8
# of Efficient-cores : 12
Total Threads : 28
Max Turbo Frequency : 5.6 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency : 5.6 GHz
Performance-core Max Turbo Frequency : 5.5 GHz
Efficient-core Max Turbo Frequency : 4.3 GHz
Performance-core Base Frequency : 3.4 GHz
Efficient-core Base Frequency : 2.5 GHz
Cache : 33 MB Intel® Smart Cache
Total L2 Cache : 28 MB
Processor Base Power : 125 W
Maximum Turbo Power : 253 W

--- Supplemental Information ---
Marketing Status : Launched
Launch Date : Q4'23
Embedded Options Available : No
Use Conditions : PC/Client/Tablet | Workstation

--- Memory Specifications ---
Max Memory Size (dependent on memory type) : 192 GB
Memory Types : Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s
Max # of Memory Channels : 2
Max Memory Bandwidth : 89.6 GB/s
ECC Memory Supported : Yes

--- GPU Specifications ---
GPU Name : Intel® UHD Graphics 770
Graphics Base Frequency : 300 MHz
Graphics Max Dynamic Frequency : 1.6 GHz
Graphics Output : eDP 1.4b | DP 1.4a | HDMI 2.1
Execution Units : 32
Max Resolution (HDMI) : 4096 x 2160 @ 60Hz
Max Resolution (DP) : 7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel) : 5120 x 3200 @ 120Hz
DirectX* Support : 12
OpenGL* Support : 4.5
OpenCL* Support : 3.0
Multi-Format Codec Engines : 2
Intel® Quick Sync Video : Yes
Intel® Clear Video HD Technology : Yes
# of Displays Supported : 4
Device ID : 0xA780

--- Expansion Options ---
Direct Media Interface (DMI) Revision : 4.0
Max # of DMI Lanes : 8
Scalability : 1S Only
PCI Express Revision : 5.0 and 4.0
PCI Express Configurations : Up to 1x16+4 | 2x8+4
Max # of PCI Express Lanes : 20

--- Package Specifications ---
Sockets Supported : FCLGA1700
Max CPU Configuration : 1
Thermal Solution Specification : PCG 2020A
TJUNCTION : 100°C
Package Size : 45.0 mm x 37.5 mm
Max Operating Temperature : 100 °C

--- Advanced Technologies ---
Intel® Volume Management Device (VMD) : Yes
Intel® Gaussian & Neural Accelerator : 3.0
Intel® Thread Director : Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Intel® Speed Shift Technology : Yes
Intel® Turbo Boost Max Technology 3.0 : Yes
Intel® Turbo Boost Technology : 2.0
Intel® Hyper-Threading Technology : Yes
Intel® 64 : Yes
Instruction Set : 64-bit
Instruction Set Extensions : Intel® SSE4.1 | Intel® SSE4.2 | Intel® AVX2
Idle States : Yes
Enhanced Intel SpeedStep® Technology : Yes
Thermal Monitoring Technologies : Yes

--- Security & Reliability ---
Intel vPro® Eligibility : Intel vPro® Enterprise | Intel vPro® Essentials | Intel vPro® Platform
Intel® Hardware Shield Eligibility : Yes
Intel® Threat Detection Technology (TDT) : Yes
Intel® Active Management Technology (AMT) : Yes
Intel® Standard Manageability (ISM) : Yes
Intel® Remote Platform Erase (RPE) : Yes
Intel® One-Click Recovery : Yes
Intel® Control-Flow Enforcement Technology : Yes
Intel® Total Memory Encryption - Multi Key : Yes
Intel® AES New Instructions : Yes
Secure Key : Yes
Intel® OS Guard : Yes
Intel® Trusted Execution Technology : Yes
Execute Disable Bit : Yes
Intel® Boot Guard : Yes
Mode-based Execute Control (MBEC) : Yes
Intel® Stable IT Platform Program (SIPP) : Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp) : Yes
Intel® Virtualization Technology (VT-x) : Yes
Intel® Virtualization Technology for Directed I/O (VT-d) : Yes
Intel® VT-x with Extended Page Tables (EPT) : Yes

Rdzenie : 20 (8C+12c)
Wątki : 20 (8+12)
Zegar turbo : 5,30 GHz (Turbo Boost Max 3.0), 5,20 GHz (rdzeń P), 4,60 GHz (rdzeń E)
Zegar bazowy : 2,40 GHz (rdzeń P), 1,80 GHz (rdzeń E)
TDP : 65 W (podstawowa moc procesora), 182 W (maksymalna moc turbo)
Układ graficzny : Intel Graphics
Socket : Intel 1851 (LGA1851)
Zgodność chipsetu : B860, H810, W880, Z890
Nazwa kodowa : Arrow Lake-S
Architektura : Lion Cove (rdzeń P) + Skymont (rdzeń E)
Produkcja : TSMC 3nm
Pamięć podręczna L2 : 36 MiB (8x 3 MiB + 3x 4 MiB)
Pamięć podręczna L3 : 30 MiB
Kontroler pamięci : Dwukanałowa pamięć DDR5, maks. 192 GB
Kompatybilność pamięci : maks. DDR5-5600 UDIMM (PC5-44800, 89,6 GB/​s), maks. DDR5-6400 CUDIMM (PC5-51200, 102,4 GB/​s)
Wsparcie ECC : Tak
SMT : NIE
Odblokowany mnożnik : NIE

Funkcje procesora :
AES-NI, AMT, AVX, AVX2, Boot Guard, CET, DL Boost, EIST, GNA 3.5, Hardware Shield, Idle States, Instruction Set 64bit (Intel 64), ISM, MBEC, One-Click Recovery, OS Guard, RPE, Secure Key, SIPP, Speed Shift, SSE4.1, SSE4.2, TDT, Thermal Monitoring, Thread Director, Thunderbolt 4, Total Memory Encryption - Multi Key, TVB, TXT, VMD, VT-d, VT-rp, VT-x, VT-x EPT, XD Bit

Linie PCIe : 24x PCIe 5.0 (dostępne: 20)
Interfejs chipsetu : DMI 4.0, 16 GT/s (PCIe 4.0 x8)
Moc obliczeniowa sztucznej inteligencji (NPU) : 13 TOPS (Intel AI Boost), całkowita maksymalna wydajność: 25 TOPS
Brak dołączonego wentylatora
Temperatura maksymalna. : 105°C (złącze)

Zegar iGPU : 0,30-1,95 GHz
Jednostki iGPU : 4Xe/​64EU/​512SP
Architektura iGPU : Xe-LPG+
Interfejs iGPU : DP 2.1 UHBR20 (7680x4320@60Hz), eDP 1.4b (3840x2400@60Hz), HDMI 2.1 (7680x4320@60Hz)
Funkcje iGPU : Obsługa 4 wyświetlaczy, 2 silniki kodeków /​ dekodery wideo, Intel Quick Sync Video, kodowanie/​dekodowanie AV1, kodowanie/​dekodowanie H.265, kodowanie/​dekodowanie VP9, ​​HDCP 2.3, DirectX 12.1, OpenGL 4.5, OpenCL 3.0, Vulkan 1.0
Moc obliczeniowa iGPU : 2,05 TFLOPS (FP32)
Moc obliczeniowa sztucznej inteligencji (NPU) : 13 TOPS (Intel AI Boost), całkowita maksymalna wydajność: 21 TOPS

--- Essentials ---
Product Collection : Intel® Core™ i7 Processors (14th gen)
Code Name : Products formerly Raptor Lake
Vertical Segment : Desktop
Processor Number : i7-14700F
Lithography : Intel 7

--- CPU Specifications ---
Total Cores : 20
# of Performance-cores : 8
# of Efficient-cores : 12
Total Threads : 28
Max Turbo Frequency : 5.4 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency : 5.4 GHz
Performance-core Max Turbo Frequency : 5.3 GHz
Efficient-core Max Turbo Frequency : 4.2 GHz
Performance-core Base Frequency : 2.1 GHz
Efficient-core Base Frequency : 1.5 GHz
Cache : 33 MB Intel® Smart Cache
Total L2 Cache : 28 MB
Processor Base Power : 65 W
Maximum Turbo Power : 219 W

--- Supplemental Information ---
Marketing Status : Launched
Launch Date : Q1'24
Embedded Options Available : No
Use Conditions : PC/Client/Tablet

--- Memory Specifications ---
Max Memory Size (dependent on memory type) : 192 GB
Memory Types : Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s
Max # of Memory Channels : 2
Max Memory Bandwidth : 89.6 GB/s

--- Expansion Options ---
Direct Media Interface (DMI) Revision : 4.0
Max # of DMI Lanes : 8
Scalability : 1S Only
PCI Express Revision : 5.0 and 4.0
PCI Express Configurations : Up to 1x16+4 | 2x8+4
Max # of PCI Express Lanes : 20

--- Package Specifications ---
Sockets Supported : FCLGA1700
Max CPU Configuration : 1
Thermal Solution Specification : PCG 2020C
TJUNCTION : 100°C
Package Size : 45.0 mm x 37.5 mm
Max Operating Temperature : 100 °C

--- Advanced Technologies ---
Intel® Volume Management Device (VMD) : Yes
Intel® Gaussian & Neural Accelerator : 3.0
Intel® Thread Director : Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
Intel® Speed Shift Technology : Yes
Intel® Turbo Boost Max Technology 3.0 : Yes
Intel® Turbo Boost Technology : 2.0
Intel® Hyper-Threading Technology : Yes
Intel® 64 : Yes
Instruction Set : 64-bit
Instruction Set Extensions : Intel® SSE4.1 | Intel® SSE4.2 | Intel® AVX2
Idle States : Yes
Enhanced Intel SpeedStep® Technology : Yes
Thermal Monitoring Technologies : Yes

--- Security & Reliability ---
Intel® Standard Manageability (ISM) : Yes
Intel® Control-Flow Enforcement Technology : Yes
Intel® AES New Instructions : Yes
Secure Key : Yes
Intel® OS Guard : Yes
Execute Disable Bit : Yes
Intel® Boot Guard : Yes
Mode-based Execute Control (MBEC) : Yes
Intel® Virtualization Technology (VT-x) : Yes
Intel® Virtualization Technology for Directed I/O (VT-d) : Yes
Intel® VT-x with Extended Page Tables (EPT) : Yes
