--- Cechy szczególne ---
Solidna jak Skała
- 5 Power Phase
Aktualizacje EZ
- Automatyczny Instalator Sterowników ASRock
--- CPU ---
- Supports 10th Gen & 11th Gen Intel® Core™ Processors (LGA1200)
- Supports Intel® Turbo Boost Max 3.0 Technology
--- Chipset ---
- Intel® H470
--- Pamięć ---
- Dual Channel DDR4 Memory Technology
- 2 x DDR4 DIMM Slots
- Supports DDR4 3200 / 2933 / 2800 / 2666 / 2400 / 2133 non-ECC, un-buffered memory*
- Wsparcie dla modułów pamięci ECC UDIMM (praca w trybie non-ECC )
- Max. capacity of system memory: 64GB
- Supports Intel® Ekstremalny Profil Pamięci (XMP) 2.0
- 15μ Gold Contact in DIMM Slots
*11th Gen Intel® Core™ (i9/i7/i5) support DDR4 3200 natively; Core™ (i3), Pentium® and Celeron® support DDR4 2666 natively.
10th Gen Intel® Core™ (i9/i7) support DDR4 2933 natively; Core™ (i5/i3), Pentium® and Celeron® support DDR4 2666 natively.
--- BIOS ---
- 128Mb AMI UEFI Legal BIOS with GUI support
Karta graficzna
- 1 x HDMI
Intel® 11th Gen Processors support HDMI 2.0, HDCP 2.3 and max. Rozdzielczośćup to 4K 60Hz
Intel® 10th Gen Processors support HDMI 1.4, HDCP 2.3 and max. Rozdzielczośćup to 4K 30Hz
- 1 x DVI-D, supports HDCP 2.3 and max. Rozdzielczośćup to Full HD (1920x1200) 60Hz
- 1 x D-Sub, supports max. Rozdzielczośćup to Full HD (1920x1200) 60Hz
*Technologie Intel® UHD Graphics Built-in Visual oraz wyjścia obrazu mogą być obsługiwane tylko przez procesory wyposażone w zintegrowane GPU.
Specyfikacje grafiki mogą się różnić w zależności od typu procesora.
--- Audio ---
- 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
--- LAN ---
- Gigabit LAN 10/100/1000 Mb/s
- Realtek 8111H
--- Sloty ---
Intel® 11th Gen & 10th Gen Processors:
- 1 x PCIe 4.0 x16 Slot (PCIE1)*
Intel® 11th Gen Processors support PCIe 4.0 x16
Intel® 10th Gen Processors support PCIe 3.0 x16
Intel® H470 Chipset:
- 1 x PCIe 3.0 x1 Slot (PCIE2)*
*Obsługa bootowania z dysków NVMe SSD
--- Magazynowanie ---
Chipset:
- 1 x Ultra M.2 Socket (M2_1, Key M), supports type 2260/2280 SATA3 6.0 Gb/s & PCIe Gen3x4 (32 Gb/s) modes*
- 4 x SATA3 6.0 Gb/s Connectors
*Supports Intel® Optane™ Technology
Obsługa bootowania z dysków NVMe SSD
RAID
- Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA Dyski
--- USB ---
- 6 x USB 3.2 Gen1 (4 Rear, 2 Front)
- 6 x USB 2.0 (2 Rear, 4 Front)
*All USB ports support ESD Protection
--- Złącza ---
- 1 x COM Port Header
- 1 x SPI TPM Header
- 1 x Chassis Intrusion and Speaker Header
- 1 x CPU Fan Connector (4-pin)*
- 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**
- 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)***
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
- 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
*CPU_FAN1 supports the fan power up to 1A (12W).
**CPU_FAN2/WP supports the fan power up to 2A (24W).
***CHA_FAN1~2/WP support the fan power up to 2A (24W).
CPU_FAN2/WP and CHA_FAN1~2/WP can auto detect if 3-pin or 4-pin fan is in use.
--- Tylny panel ---
- 1 x PS/2 Mouse/Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 2 x USB 2.0 Ports
- 4 x USB 3.2 Gen1 Ports
- 1 x RJ-45 LAN Port
- HD Audio Jacks: Line in / Front Speaker / Microphone
--- Oprogramowanie i UEFI ---
Software
- ASRock Motherboard Utility (A-Tuning)
UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- Automatyczny Instalator Sterowników ASRock
- ASRock Funkcja Instant Flash
- ASRock Internet Flash
- ASRock Easy RAID Installer
*Te narzędzia można pobrać z Live Update & APP Shop.
--- Akcesoria ---
- 1 x Instrukcja Obsługi
- 1 x I/O Shield
- 2 x SATA Data Cables
- 1 x Screw for M.2 Socket
--- Wymiary ---
- Micro ATX Form Factor: 9.1-in x 7.8-in, 23.1 cm x 19.8 cm
--- System operacyjny ---
- Microsoft® Windows® 10 64-bit / 11 64-bit
--- Certyfikaty ---
- FCC, CE
- ErP/EuP ready (ErP/EuP ready power supply is required)
